1/2" 3/4" 1" 1-1/4" 1-1/2" 2" Electric Ball Valve Brass Air Conditioning Floor Heating Solenoid Valve Three-Way AC220V
Structure : Diaphragm
Certification : CE
Port Size : 1/2"(DN15), 3/4"(DN20), 1"(DN25), 1-1/4"(DN32), 1-1/2"(DN40), 2"(DN50)
Pressure : Low Pressure
Power Source : AC
Standard or Nonstandard : Standard
Actuator Mode : Without Manual And Instruction
Media : Water
Material : Brass
Temperature of Media : Normal Temperature
NC or NO : Normally Closed
voltage : 220VAC 24VAC 24VDC 12VDC
Valve1 : Motorized Ball Valve
Valve2 : electric crane
Medium: Cold water, Hot water or 50% Glycol solution
Type: Normally closed
Body material: Brass
Operation Mode: Three-Wire Two-Control
Driving voltage: 220VAC 24VAC 24VDC 12VDC
Applicable medium temperature: 0-90℃
Applicable ambient temperature: 0-60℃
Power consumption: 6 VA (only when the valve is opened and closed)
Action time: 10-15 S
Valve body pressure: 1.6 Mpa
Lead length: 30 CM
Connection method: G internal thread
