Model Number : ICharger PWM N120/1220/1230
Maximum Current : 60A/50A/40A/30A/20A/10A
is_customized : Yes
Certification : NONE
Application : Charger Controller,Solar System Controller,Voltage Controller,Solar Working Station,Lighting Controller
Charging current : 60A 50A 40A 30A 20A 10A
Application : solar energy
Float charge : 13.7V (defaul,adjustable)
Discharge stop : 10.7V (defaul,adjustable)
Discharge reconnect : 12.6V (defaul,adjustable)
Max Solar Panel input : 50V(for 24V battery) 25V(for 12V battery)
USB : Dual USB 5V 2.5A Max
Please Note For EU buyers:
POWLAND EU storehave been opened.You NO Need To pay VATfor purchases from
EU store.The price drops by 30-300 Euros.EU Store deliver faster timeliness and lower prices! ! !
EU buyers click on the link to buy:https://www.aliexpress.com/store/912467552?spm=a2g0o.productlist.0.0.6fe77a7fFf083O
If you have any questions, please feel free to contact us, thank you
60A/50A/40A/30A/20A/10A Solar Charger Controller 12V 24V Auto PWM Controllers LCD Display 5V Dual USB Output Controller
This is NEW Solar Controller ,It can fully meet your home Photovoltaic system(including home lighting system )requirements .It can recongize 12V and 24V Lead acid ,Gel battery automatically
If you want to use other type battery,you need to set up.Such as Lithium battery charging,full protection 12.2V,discharge 9.5V,restart 11.5V.
There are optional 10A 20A 30A model
10A:
if your battery is 12V ,the max solar panel input is 25V 120W
if your battery is 24V ,the max solar panel input is 50V 240W
20A:
If your battery is 12V, the max solar panel input is 25V 240W
if your battery is 24V, the max solar panel input is 50V 480W
30A:
if your battery is 12V ,the max solar panel input is 25V 360W
if your battery is 24V ,the max solar panel input is 50V 720W
1.Build-in industrial micro controller.
2.Big LCD display,all adjustable parameter.
3.Fully 4-stage PWM charge management.
4.Build-in short-circuit protection,open-circuit protection,reverse protection,over-load protection.
MODEL | PWM 10A | PWM 20A | PWM 30A | PWM 40A | PWM 50A | PWM 60A |
Battery Voltage | 12V 24V Auto | |||||
Charging Current | 10A | 20A | 30A | 40A | 50A | 60A |
Discharging Current | 10A | 10A | 10A | 20A | 30A | 30A |
Max Solar input | 50V(for 24V battery) 25V(for 12V battery) | |||||
Equalization | 14.4V(Sealed) 14.2V(Gel) 14.6V(Flood) | |||||
Float charge | 13.7V(defaul,adjustable) | |||||
Discharge stop | 10.7V(defaul,adjustable)10.7V(defaul,adjustable) | |||||
Discharge reconnect | 12.6V(defaul,adjustable) | |||||
Charge reconnect | 13V | |||||
Voltage of open light | Solar Panel 8V(Light lights delay) | |||||
Voltage of close light | Solar Panel 8V(Light off delay) | |||||
USB output | 5V/3A | |||||
Self-consume | <10mA | |||||
Operating temperature | -35°C~+60°C | |||||
Size | 133.5*70*35mm | 133.5*70*35mm | ||||
*all red color voltage X2 ,while using 24V system.
Connection:
1.Connect the battery to the charge regulator - plus and minus.
2.Connect the photovoltaic module to the regulator - plus and minus.
The reverse order applies when deinstalling!
An improper sequence order can damage the controller!
